In order to guarantee a uniform user experience, we have set up a number of best practices for Extensions

1. Advanced Simplicity

In order to display only the required fields in Cognigy.AI, we use the principle of advanced simplicity. All optional fields should be outsourced to "sections".

1.1 Storage Options

In most cases, an extension returns some kind of value -- e.g. an HTTP Request result. Now one needs to decide if the information should be stored in the context of the whole conversation or just in the input object of the next message. Therefore, please add the following code snippet to the fields in your extension's code:

Fields:

{
	key: "storeLocation",
	type: "select",
	label: "Where to store the result",
	params: {
		options: [
			{
				label: "Input",
				value: "input"
			},
			{
				label: "Context",
				value: "context"
			}
		],
		required: true
	},
	defaultValue: "input"
},
{
	key: "inputKey",
	type: "cognigyText",
	label: "Input Key to store Result",
	defaultValue: "httprequest",
	condition: {
		key: "storeLocation",
		value: "input"
	}
},
{
	key: "contextKey",
	type: "cognigyText",
	label: "Context Key to store Result",
	defaultValue: "httprequest",
	condition: {
		key: "storeLocation",
		value: "context"
	}
}

Section:

 {
	key: "storageOption",
	label: "Storage Option",
	defaultCollapsed: true,
	fields: [
		"storeLocation",
		"inputKey",
		"contextKey"
	]
}

Form:

 form: [
	{ type: "section", key: "storageOption" },
	],

With this choice, one can include the following code to handle the user's decision:

if (storeLocation === "context") {
	api.addToContext(contextKey, resultObject, "simple");
} else {
	// @ts-ignore
	api.addToInput(inputKey, resultObject);
}

2. Outsource Helper Functions

If possible, the function of the extension should only focus on the use of the Cognigy API for configuration. All other steps should be outsourced to auxiliary functions. Accordingly, you would create your own function for an HTTP request.

3. Connection

Whenever your extension requires an authentication

Fields:

{
	key: "connection",
	label: "API Key",
	type: "connection",
	params: {
		connectionType: "api-key",
		required: true
	}
},

Form:

  • First position
form: [
	{ type: "field", key: "connection" },
]

4. Dependent Fields

In case some fields are only relevant depending on other field configurations, you can improve the user experience of your Node by only displaying the "necessary" fields.



Note: "nesting" conditions with { and: [ ] } and { or: [ ] } is only available from Cognigy.AI v4.1.4 on.

{
	key: "method",
	type: "select",
	label: "Request Method",
	params: {
		options: [
			{ label: "Get", value: "get" },
			{ label: "Post", value: "post" },
			{ label: "Put", value: "put" },
			{ label: "Patch", value: "patch" },
		],
		required: true,
	},
	defaultValue: "get",
},
{
	key: "bodyType",
	type: "select",
	label: "Request Body Type",
	params: {
		options: [
			{ label: "None", value: "none" },
			{ label: "Plain Text", value: "text" },
			{ label: "JSON", value: "json" },
		],
		required: true,
	},
	defaultValue: "none",
	condition: {
		key: "method",
		value: ["post", "put", "patch"],
	},
},
{
	key: "bodyText",
	type: "cognigyText",
	label: "Request Body (Text)",
	params: {
		multiline: true,
	},
	defaultValue: "",
	condition: {
		and: [
			{
				key: "method",
				value: ["post", "put", "patch"],
			},
			{
				key: "bodyType",
				value: "text",
			},
		],
	},
},
{
	key: "bodyJSON",
	type: "json",
	label: "Request Body (JSON)",
	defaultValue: "",
	condition: {
		and: [
			{
				key: "method",
				value: ["post", "put", "patch"],
			},
			{
				key: "bodyType",
				value: "json",
			},
		],
	},
},
{
	key: "bodyCompression",
	type: "checkbox",
	label: "Apply Compression to Request Payload",
	defaultValue: false,
	condition: {
		and: [
			{
				key: "method",
				value: ["post", "put", "patch"],
			},
			{
				or: [
					{
						and: [
							{
								key: "bodyType",
								value: "text",
							},
							{
								key: "bodyText",
								value: "",
negate: true }, ], }, { and: [ { key: "bodyType", value: "json", }, { key: "bodyJSON", value: "",
negate: true }, ], }, ], }, ], }, }
